Sliding closure A 500 V/24 Item Number: 56022512

The decoupled sliding closure

Decoupled, two-part sliding closure A 500 V/24 for plaster and ETICS facades with compensation of thermal length variation…
View product description

Selection number	202205 000 01
Length	34 mm
Width	110 mm
Height	25.5 mm
Projection	110 mm
Height Drip Edge	30 mm
deduction measurement	5 mm
plaster edge	24 mm
Orientation	Left
Surface quality	Normal quality
Material Thickness	1.8 mm
Packaging Unit	30 Stk

Matching products

Window sill Standard

Decoupled, two-part sliding closure A 500 V/24 for plaster and ETICS facades with compensation of thermal length variation of +2 mm/-2 mm. Provision for integration of a roller shutter guide rail. Water tightness under heavy rain tested up to 1,950 Pa. Component of the BUG System 500 window sill system tested for water tightness under heavy rain. Material: aluminium and special plastic. Plaster edge (width): 24 mm. Drip edge: 30 mm.
