RS-rail KP 5081 W Item Number: 20028153

The KP 5081 W rain protection rail is a weather rail with a transom cover designed for a rebate width of 25 millimetres…
View product description

Selection number	262058 000 03
Length	6,000 mm
Width	81 mm
Height	62.62 mm
Surface quality	Normal quality
Hardness level	T66
Perforation	perforated
Hole spacing	230 mm
Packaging Unit	24 m

The KP 5081 W rain protection rail is a weather rail with a transom cover designed for a rebate width of 25 millimetres and available with thermal break. The rail is installed by bolting it in place. The product range includes precision-fit end caps to seal the construction securely. For details of the visual design, please refer to the construction drawing in the download section.
