RS-rail GTR 25.46 K Item Number: 20028048

The GTR 25.46 rain protection rail is a large-capacity rail with a transom cover, designed for a rebate width of 25 millimetres…
View product description

Selection number	260052 601 03
Length	6,000 mm
Width	43.2 mm
Height	51.15 mm
Surface quality	Normal quality
Hardness level	F22
Color	E6 / EV1
Packaging Unit	48 m

The GTR 25.46 rain protection rail is a large-capacity rail with a transom cover, designed for a rebate width of 25 millimetres and available with thermal break. The rail is installed by hammering it into place. The product range includes precision-fit end caps to seal the construction securely. For details on the optical design, please refer to the construction drawing in the download.

Note: The TRDN 25.48K rain protection rail is also available especially for wood-aluminium composite windows, e.g. Vienna windows.
