Fixed glazing profile AWF 2 Item Number: 20033924

Multi-part aluminium system for the protection of Vienna windows, consisting of profiles for the frame, setting bar, transom,…
View product description

Selection number	660532 000 01
Length	6,000 mm
Width	67 mm
Height	23.5 mm
Hardness level	T66
Profile shapes	inclined
Production type	Welded corner connection, Mechanical corner connection
Exposed Surface	Recessed System

System components

Cover profile AWF 2

Fixed glazing profile AWF 2

Sash profile AWF 2

Frame profile AWF 2

Setting bar profile AWF 2

Bar profile AWF 2

Door base profile AWF 2

Multi-part aluminium system for the protection of Vienna windows, consisting of profiles for the frame, setting bar, transom, fixed glazing, sash, mullion, glazing bars and door base. Combine the system with weather bars tailored to the specific features of Vienna windows:
