Butt connector H 500 D Item Number: 56014620

H 500 D butt connector for secure connection of window sill butts. Water tightness under heavy rain tested up to 1,950…
View product description

Selection number	206151 646 01
Length	25 mm
Width	70 mm
Height	52 mm
Projection	70 mm
Height Drip Edge	40 mm
Height Screw Plate	25 mm
deduction measurement	4 mm
Seal	Yes
Color	E6 / C33
Packaging Unit	10 Stk

Matching products

Window sill Softline Plus

H 500 D butt connector for secure connection of window sill butts. Water tightness under heavy rain tested up to 1,950 Pa. Compensation of thermal length variation +3 mm/-3 mm. With a spring-based design, expansion compensation is +4 mm/-4 mm. Component of the BUG System 500 window sill system tested for water tightness under heavy rain. Material: aluminium and corner-vulcanised EPDM seal.

Note: Expansion compensation is via a compensating spring effect with an integrated zero position. This defined compensation allows movement and expansion during temperature fluctuations on both sides of the window sill.
