AP 16.23 Item Number: 20027949

Weather protection rails for wooden windows

The rebate-independent rain protection rail AP 16.23 D is an attachment rail and is suitable for wide cover frames. It reduces…
View product description

Selection number	211118 601 03
Length	6,000 mm
Width	23 mm
Height	50 mm
Surface quality	Anodised quality
Hardness level	T66
Color	E6 / EV1
Packaging Unit	108 m

The rebate-independent rain protection rail AP 16.23 D is an attachment rail and is suitable for wide cover frames. It reduces condensation and allows rainwater to drain away to the outside via the cover frame in a controlled manner. The AP 16.23 D is delivered with a retracted seal. Precision-fit end caps are supplied to seal the construction securely. When installed correctly, it ensures water tightness under heavy rain in accordance with EN 14351-1.
